T+A Criterion TCD 310S lattiakaiuttimet, siisti vaihtopari, pianovalkoinen, sijainti Hyvinkää. Huom vain nouto, ei tehdaspaketteja.
The TCD 310 S is the medium sized floor-stander in the TCD series, although it extends to a good metre high, so it is not really small. It is of very similar construction to the TCD 210 S; just the mid-range and bass units are slightly smaller. The TCD 310 S is another fully developed transmission-line floorstanding speaker with a very long line. Two 17 cm bass units with low free air resonance are accurately tuned to the transmission line, and their extremely hard, embossed carbon cones generate very deep, accurate bass at high pressure. Two 15 cm mid-range units and the Waveguide high-frequency dome form an acoustic unit which we have designated CD - Constant Directivity. The mid-range units are ingenious designs which effortlessly cover the full vocal range from 250 to 2200 Hz, and their dynamic, lively nature creates an amazingly natural sound. The use of two mid-range drivers helps to optimise the speakers’ radiation characteristics as well as dramatically increasing their ability to handle high levels, because the excursion and power handling required of each individual driver are halved. The same superb drive units are also employed in our SOLITAIRE® CWT 2000 speaker. The woven dome handles even the most severe dynamic peaks in a fast, airy manner, without any trace of hardness or sharpness. On the one hand the large Waveguide perfectly links the unit’s radiation characteristics to those of the mid-range drivers, and at the same time causes a timing delay in the tweeter response, providing a further improvement in transitional behaviour. The TCD 310 S is fitted with a sophisticated double-sided threeway cross-over unit (FSR). The circuit effortlessly processes even the highest signal levels, and ensures that the three frequency ranges are matched perfectly to the drive units. The impressive imaging and radiation qualities over the full frequency range are directly due to the design of this cross-over unit. The curved cabinets offer more than just an elegant appearance - their construction provides enormous rigidity and strength: the side panels are bonded permanently to the inner case and the internal sound guides of the long transmission line. These measures helped to achieve even greater dynamic range and higher pressure in the extreme bass.
Technische Daten:
Nennbelastbarkeit: 160 Watt
Musikbelastbarkeit: 220 Watt
Impedanz: 4 Ohm
Minimale Impedanz: 3 Ohm
Minimale Impedanz bei: 118 Hz Maximale Impedanz: 11,5 Ohm
Maximale Impedanz bei: 1600 Hz Leistung für 94 dBSPL: 4,8 Watt
Übertragungsbereich: 28Hz - 35.000 Hz
Empfindlichkeit (1 Watt / 1 m): 87 dB Bestückung Tiefton: 2 x 170 mm Bestückung Mittelton: 2 x 150 mm Bestückung Hochton: 1 x 25 mm Trennfrequenzen: 250 Hz / 2200 Hz
Gewicht: 33kg / Stück
