Anthem MRX 740 11.2 AV Amplifier

Anthem MRX 740 11.2 AV Amplifier

The Anthem MRX 740 is an 11.2-channel AV amplifier of the new MRX generation.

11.2 Pre-Amplifier / 7 Amplifier Channel A/V receiver with Dolby Atmos, DTS:X and IMAX Enhanced. 140-watts per channel continuous power into 8 ohms. Includes ARC (Anthem Room Correction). HDMI 2.1, HDCP 2.3 supporting 8K/60Hz or 4K/120Hz

Pure Value

Anthem's MRX A/V Receivers are about maximizing audio performance that previously has been unobtainable at their respective price points. Building on the feature set of our previous models, we've added the newest version of ARC Genesis, a Redesigned and more accurate calibration microphone, Anthem's Web User Interface, integrated streaming support, object-oriented audio codecs with support for up to 15.2 channels and the clean power delivery Anthem is known for with up to 140 watts per channel.

The MRX 540, 740 and 1140 are a great way to bring premium audio to any home theater or media room. Seamlessly integrate your smart TV or projector with 7 dedicated 8K HDMI inputs that support 8K/60Hz or 4K/120Hz pass-through and 3 dedicated outputs with eARC. With MRX, you can enjoy 8K quality video from all of your 8K source devices in amazing clarity.

Complexity Simplified

At Anthem, our goal is to shape how you interact with your technology, so we went the extra mile to ensure no detail is overlooked while providing the utmost flexibility when it comes to device setup. Using a phone, tablet or laptop, owners can easily access any function or setting and make changes on the fly. Power the primary or secondary zone on and off, adjust volume, change audio modes, tweak channel trims and more, for a perfect surround sound experience. You're in control, and it's never been easier.

Advanced 8K HDMI Platform with e-ARC Support

Feel the power of every frame with the MRX Series and its advanced 8K HDMI 2.1 Platform with HDCP 2.3. Showcasing 7 dedicated 8K inputs which support 8K/60Hz or 4K/120Hz pass-through and 3 dedicated outputs with Enhanced Audio Return Channel, you can enjoy 8K quality video from all of your 8K source devices in amazing clarity. Also featuring the latest HDMI technology and specification, the MRX 540, 740 and 1140 allow you to take your home entertainment to the next level with HDR10+, Dynamic HDR10+, ALLM and VRR support. The possibilities are limitless; unlock the true potential of your media with the industry's most flexible and feature-rich HDMI platform.

Experience Gaming Like Never Before on an MRX

It's never been a more exciting time to be a gamer. With the latest consoles offering up to 4K/120Hz graphics, realistic HDR and Dolby Vision dynamic range, and Immersive Dolby Atmos sound, you have to make sure your Home Theater gear won't hold you back. Enter the MRX Series, our most feature-rich AV receivers to date!

Channel Re-Assignment

The built in high performance amplifier modules can be configured in many ways to suit the specific speaker configuration. Unused amplifier channels can be re-assigned to Bi-Amplify demanding front speakers, power surrounds, presence speakers, or a second zone (Available on MRX 1140 and MRX 740). Configure amplifier channels for your system's needs, then fully optimize the presentation with ARC Genesis.

Robust Integration

Our latest Anthem MRX series features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions. It offers IP control Capability for major third-party control devices including:

Design

At Anthem, we have one simple goal – to design, engineer and manufacture audio/video products that deliver premium performance and convenience at a reasonable price. We do this by spending thousands of hours selecting and testing components, carefully designing our own circuit topologies, and backing them with robust power supplies that ensure maximum long-term quality and reliability. We achieve this with our team at the Paradigm/Anthem Research Center and their decades of combined experience.

Anthem Remote App

Gain unprecedented command over your network-enabled Anthem A/V Receiver, Processor or Pre-amplifier.

The Anthem Remote App uses a Wifi connection to simplify the configuration of supported Anthem devices. App-based controls include volume level, muting, input selection, power, listening modes, bass, treble, level trims, menu navigation, and Anthem Room Correction (ARC) control.

ARC Genesis

ARC Genesis is the newest software that works with many ARC enabled Anthem or Paradigm products. New features include support for both Mac and Windows; new target curve adjustment options including deep bass and high frequencies; improved algorithms and much more.

ARC Genesis is backwards compatible with many Anthem and Paradigm products that are ARC or PBK enabled. For a complete list, please visit AnthemARC.com. This third generation of Anthem Room Correction software represents a significant leap forward in room correction with the most comprehensive set of features yet. ARC Genesis transforms the audio performance of compatible speakers or electronics while retaining the unique character of any room. Proprietary Digital Signal Processing (DSP) software works in tandem with a calibrated microphone (provided with many ARC and PBK enabled products) to provide Astonishing Improvements to the sound you hear.

MRX 1140 8K Specifications

PREAMPLIFIER

• Maximum Output (<0.1% THD) 5.2 VRMS, 7.1 VRMS
• Frequency Response 20Hz - 30KHz +/-0.2dB
• Frequency Response, Analog-Direct N/A
• THD+N (2 Vrms output) -100 dB
• S/N Ratio (2 Vrms output, IEC-A filter) 110 dB
• PREAMPLIFIER + AMPLIFIER (1 W OUTPUT)
• MRX 1140 / MRX 740 SNR: 91 dB ch 1-5, 86 dB others
• MRX 540 SNR: 91 dB ch 1-5

SPEAKER IMPEDANCE

• Compatible with 4 Ohms or higher impedance.

MAXIMUM CONTINUOUS OUTPUT (1% THD) MRX 1140 / MRX 740 / MRX 540

• Channels 1-5, Two Driven into 8 Ohms 140 W / 140 W / 100 W

• Channels 1-5, Two Driven into 6 Ohms 170 W / 170 W / 130 W
• Remaining Channels, Two Driven into 8 Ohms 60 W / 60W / n/a
• Remaining Channels, Two Driven into 6 Ohms 75 W / 75 W / n/a

POWER CONSUMPTION MRX 1140 / MRX 740 / MRX 540

• Typical Load 570 W / 485 W / 365W
• Standby 0.3 W / 0.3W / 0.3W
• Standby IP Control Enabled 1.8 W / 1.8W / 1.8W
• Standby HDMI Bypass Enabled 4.9 W / 4.9 W / 4.9 W

DIMENSIONS

• Height (without feet) 6" (15.24 cm)
• Height with Rackmount Kit 4U
• Width 17" (43.18 cm)
• Depth (including wifi and not power cord) 14-1/2" (36.4 cm)

WEIGHT

• MRX 1140 33.6 lb (15.2 Kg)
• MRX 740 33.2 lb (15.1 Kg)
• MRX 540 28.2 lb (12.8 kg)

POWER REQUIREMENT

• 220-240 V version: In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
