Musical power in a compact size.
The MXW70 brings amplifier power and refinement to any audio system – without the bulk of bulky power amplifiers. It can drive even the most demanding speakers with ease, making it a great addition to both minimalist and high-end setups.
The MXW70 is designed specifically to pair with the MXN10 music streamer. Together, these half-width devices create a powerful and stylish streaming system that delivers premium sound quality in a compact space.
Small but powerful
Designed in London, the MXW70 is a meticulously engineered power amplifier that delivers impressive high-fidelity power from a compact package, fitting seamlessly into an existing sound system or providing the perfect foundation for a modern, compact hi-fi setup.
Enough power
Don't let its size fool you – the MXW70 delivers 70 watts per channel of pure stereo sound, and when bridged as a mono amplifier, it delivers an impressive 250 watts of power.
Extremely compact system
Pair the MXW70 with our award-winning MXN10 music streamer for a complete, compact hi-fi streaming system. Add the DacMagic 200M DAC for even more precise digital playback and high-resolution headphone output.
Compact size
At just 215 mm wide, the MXW70 fits easily anywhere – on a desk, in an entertainment center, or tucked neatly away in a cabinet.
Full metal construction
There are no compromises in the construction – the MXW70 is equipped with a high-quality, all-metal enclosure. The minimalist and timeless design is finished in the elegant Lunar Grey colour, which is a Cambridge Audio signature.
Specifications – Cambridge Audio MXW70 Compact Amplifier
- 2 x 70W (8Ω, stereo mode)
- 2 x 125W (4Ω, stereo mode)
- 250W (8Ω, mono connection)
- Amplification technology: Class D, Hypex nCORE
- Frequency response: 10Hz – 30kHz (–1dB)
- Power supply: SMPS (switching mode power supply)
- Bi-wiring: Possible, one pair of speaker outputs
- Analog RCA inputs
- Balanced XLR input
- 12V Trigger
- Speaker outputs
- Other outputs
- 12V Trigger pass-through
- Total Distortion (THD+N, unweighted): <0.015% @ 5W / 8Ω
- Signal-to-noise ratio (1W / 20kHz bandwidth): 92dB (XLR), >89dB (RCA)
- Channel separation @ 1kHz: <–82dB
- Gain: 22.2dB (XLR), 28.8dB (RCA)
- Input sensitivity: 3.6V (mono XLR), 1.65V (mono RCA), 0.9V (stereo RCA), 1.9V (stereo XLR)
- Input impedance: 22kΩ (RCA), 35kΩ (XLR)
- Damping factor: 180 @ 1kHz / 8Ω
- Maximum power consumption: 300W
- Standby power consumption: <0.5W
- Dimensions (H x W x D): 57 x 215 x 215 mm
- Weight: 1.65 kg
Package contents
- Power cords
- Welcome letter
- Registration card
- Safety guide
