Description
YAMAHA RX-A2A
7.2 AV receiver
Enter the new world of home theater with the RX2A model.
This AV receiver will completely change the way you watch and listen to entertainment in your home. In addition to that, an extraordinary number of features means a lot of different possibilities to enjoy entertainment.
UNHEARD SOUND
- Cinema DSP3D
- Dolby Atmos with Height Virtualization (software update)
- Compressed Music Enhancer sound improvement
- High Slew Rate- Fast response amplifiers
MOVIES AND GAMES, BETTER THAN EVER
- 8k and 4K/120HZ. (software update)
- HDR10+, HDR, HLG and DOLBY VISION
- Gaming specific functions (ALLM, VRR, QMS, QFT) (software update)
- Multiple HDMI connections with the latest technology (software update)
ADVENTURE
- Supported ART frame with vibration-absorbing central support
- High Grade remote control
- 5-year warranty (online registration)
SIMPLE TO INSTALL, EASY TO USE
- AV-setup Guide commissioning application
- MusicCast control application
- Alexa and Google Assistant voice control support (availability depends on region)
- Siri control with Airplay2 feature
MADE YOUR HOME
- YPAO™ RSC with multipoint measurement
- MusicCast Surround wireless rear speaker option
- Impressive Design
HDR10+, 8K/60Hz, 4K/120Hz*
HDR10+ not only reproduces the dynamic range (brightness-to-dark ratio) of video content frame by frame (or even frame by frame), it also reproduces the characteristics between bright and dark so that important details can be preserved. The images displayed in this way better correspond to reality and how they are supposed to look.
4K/120Hz makes ultra-fast UHD video clear and extremely accurate, which is an excellent advantage during sports, action movies, high-performance gaming and VR gaming.
* These functions are available via FW update.
Dolby Atmos® Height Virtualization *
Dolby Atmos equipped with Height Virtualization technology simulates Atmos sound reproduction in forward-facing speaker elements when the system does not have ceiling or upward-facing speakers. You can configure up to five speakers to create the soundscape of two ceiling speakers, or use all seven channels to simulate the powerful effect of four overhead speakers.
Experience all the dimensions of the Dolby Atmos system. Enjoy a 5.1-channel surround sound system and two additional ceiling speakers or two Dolby Atmos ceiling reflectors that enable dramatic ceiling sound effects and true surround sound. Includes a Dolby Surround mixer for older content.
* This function is available via FW update.
DTS:X
The immersive DTS:X sound format places the sound in the space in its natural place of manifestation, which creates a realistic and multidimensional sound reproduction. The included DTS Neural:X feature makes your movies even more immersive and realistic.
Advantage of High Slew Rate amplifiers
The High Slew Rate amplifier terminals used by Yamaha promote accurate signal transfer, which is especially suitable for high-resolution audio signals. Yamaha's newly developed circuit technology achieves both fast signal speed and stable signal transmission. Slew Rate: How quickly the amplifier reacts to rapid changes in the incoming signal.
Center support ART
Yamaha's Anti Resonance Technology (ART) includes a central support placed in the middle of the unit. It provides dynamic and accurate sound reproduction by suppressing vibration caused by the transformer, power transistors and heat exchanger, as well as vibration that may be caused by the sound of the speakers.
YPAO™RSC/Multi-Point audio optimization
YPAO RSC (Reflected Sound Controller) sound optimization analyzes room acoustics with the included YPAO calibration microphone and tunes your system to produce incredible sound. RSC corrects early reflections to achieve studio-level sound quality. YPAO 3D automatically optimizes the sound parameters and thus helps to achieve the best possible 3D sound field efficiency for CINEMA DSP HD3, Dolby Atmosei and DTS:X. 64-bit highly accurate EQ calculation produces the most natural room acoustics.
CINEMA DSP 3D for movies, music and games
Yamaha's special and unique technology that creates sound fields was developed by combining data collected from sound fields with digital signal processing. Yamaha collected sound field data from famous concert halls and music clubs around the world, using its extensive experience in concert hall design, speaker systems and mixing. By digitizing this extensive information and including it in special LSI devices, it is possible to create spaces that are impressively equivalent to concert halls with home devices. Immerse yourself in the amazingly realistic sound of movies and step deep into the world of theater sound.
Wireless rear speakers
Pair this AV receiver with a MusicCast 50 or MusicCast 20 wireless speaker and you'll be amazed at how easily you can create a home theater with wireless rear speakers. In addition, you get amazingly realistic sound without the mess of cables. You can easily turn your living room into a special entertainment space where you can enjoy movies and music to the fullest
SCENE speed dials, easier and faster.
The RXA2A model has four SCENE speed dials. You can set different inputs, sound field programs, Music enhancement circuit, HDMI output and much more. You can set speed dial for sources such as FM radio and internet radio stations, music streaming services, USB device or PC. Make the setting and hold down the SCENE key for a while, the setting is saved behind the selection key.
Control easily with the MusicCast control app
Use the MusicCast app on your smartphone or tablet to control and operate the RX-A2A. You can use the app to control several MusicCast products and share music between devices wirelessly.
Multi-room audio playback - MusicCast
Imagine sharing all the music you love at home. MusicCast covers everything from traditional vinyl record sharing, AirPlay®, Bluetooth® music streaming services * and even TV audio sharing. On top of that, MusicCast is designed with audio playback in mind, supporting High Resolution audio formats such as Apple Lossless (ALAC) up to 96 kHz, WAV, FLAC and AIFF up to 192 kHz
AirPlay2
AirPlay 2 adds the ability to stream Apple Music and other streaming services to multiple MusicCast devices in your home. Easily control it from your iPhone or iPad, connect it to Home Pod or just use voice control and ask Siri for help.
Music streaming support
Explore the world of music with built-in music streaming services. Synchronization of playlists and tracks from a smartphone or computer to an AV receiver, music streaming services make searching and listening to music easy.
eARC
Unlock the full potential of 4K content. Enhanced Audio Return Channel (also known as eARC) is the next generation of ARC - available from Yamaha. eARC delivers full-resolution, multi-channel audio formats such as Dolby® TrueHD and DTS-HD® through the existing HDMI connection, giving you the most realistic surround sound experience for your favorite movies and moments.
A significant advantage of the new AVENTAGE model series products is the extended warranty period.
When the consumer registers the product on Yamaha's website within 6 months of purchase, he gets +36 months on the amplifier. guarantee
Technical information:
|
RX-A2A |
||
|
Amplifier |
Channel number |
7.2. |
|
Output power (1kHz, 1ch driven) |
125 W (8 ohm, 0.9% THD) |
|
|
Output power (20Hz-20kHz, 2ch driven) |
100 W (8 ohm, 0.06% THD) |
|
|
Maximum output power (1kHz, 1ch driven) (JEITA) |
160 W (6 ohm, 10% THD) |
|
|
High Slew Rate amplifiers |
Yes |
|
|
Surround Sound Processing |
CINEMA DSP |
Yes |
|
DSP programs |
17 |
|
|
Separate adjustment of speech volume |
Yes |
|
|
Virtual overhead speaker support |
Yes |
|
|
Virtual Surround Back rear speakers |
Yes |
|
|
Lifting of the central canal |
Yes |
|
|
SILENT CINEMA headset Surround / Virtual CINEMA DSP |
Yes |
|
|
Dolby Atmos |
Yes |
|
|
Dolby Atmos Height Virtualizer |
Yes |
|
|
Dolby TrueHD |
Yes |
|
|
Dolby Digital Plus |
Yes |
|
|
Dolby Surround |
Yes |
|
|
DTS:X |
Yes |
|
|
DTS-HD Master Audio |
Yes |
|
|
File Format |
MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32 -bit, DSD: up to 11.2 MHz |
|
|
Audio features |
Pure Direct |
Yes |
|
Compressed Music Enhancer |
Yes |
|
|
YPAO multipoint measurement |
Yes |
|
|
YPAO Volume |
Yes |
|
|
Adaptive DRC (Dynamic Range Control) |
Yes |
|
|
Customizable Volume & Max Volume settings |
Yes |
|
|
Bi-amp amplification |
Yes |
|
|
Sound delay adjustment |
Yes (0-500 ms) |
|
|
DA converter |
384 kHz / 32-bit BB PCM5102A |
|
|
HDMI eARC |
Yes |
|
|
Video features |
HDMI Audio Return Channel (ARC) |
Yes |
|
HDMI feedthrough |
8K / 60 Hz, 4K / 120 Hz (software update) |
|
|
HDMI upscaling |
Yes to 4K quality |
|
|
HDR 10+ |
Yes (Software Update) |
|
|
VRR/ALLM/QMS/QFT |
Yes (Software Update) |
|
|
MusicCast Surround |
Yes |
|
|
Connectivity |
HDMI in/out |
7/1. |
|
HDMI CEC |
Yes |
|
|
USB input |
Yes |
|
|
Network interface (Ethernet) |
Yes |
|
|
WiFi |
Yes (2.4 / 5 GHz) |
|
|
AirPlay2 |
Yes |
|
|
Bluetooth |
Yes (SBC / AAC) |
|
|
Front AV connection |
USB |
|
|
Digital Audio In/Out: Optical |
1 / 0 |
|
|
Digital Audio in/out: Coax |
1 / 0 |
|
|
Analog Audio in/out |
4 / 0 |
|
|
Phono turntable connection |
Yes |
|
|
Preout |
2.2-ch |
|
|
Headphone jack |
1 |
|
|
FM/AM radio |
Yes |
|
|
Screen control |
Yes |
|
|
Use |
SCENE shortcuts |
Yes (8 settings) |
|
Application control |
Yes (iPhone / iPad / Android phone / tablet) |
|
|
Web browser control |
Yes |
|
|
Remote control |
Yes (Premium) |
|
|
Zone 2 Audio output |
Preout |
|
|
Confirmed Zone |
Zone 2 |
|
|
+12V Trigger Output |
1 |
|
|
Party Mode |
Yes |
|
|
Standby power consumption (IR only) |
0.1W |
|
|
Change |
Automatic power off |
Yes |
|
ECO mode |
Yes |
|
|
Dimensions W x H x D |
435 x 171 x 372 mm. |
|
|
Weight |
10.2 kg |
|
|
Warranty |
24 months (online registration +36 months = 5V) |
|
